Dactyl-CC#

Modelled on the Kinesis Advantage (KA) 1|2, though missing it's combined function and program row, the Dactyl CC retains the finger and thumb key placements of the KA but opts to split board into physical halves.

• Keyboard Maintainer: Michael Johns
• Hardware Supported: Pro micro controller or clones of
• Hardware Availability: Dactyl CC GitHub

Make example for this keyboard (after setting up your build environment):

make handwired/dactyl_cc:default

Flashing example for this keyboard:

make handwired/dactyl_cc:default:flash

See the build environment setup and the make instructions for more information. Brand new to QMK? Start with our Complete Newbs Guide.

Bootloader#

Enter the bootloader in 3 ways:

• Bootmagic reset: Hold down the key at (0,0) in the matrix (usually the top left key or Escape) and plug in the keyboard
• Physical reset button: Briefly press the button on the back of the PCB - some may have pads you must short instead
• Keycode in layout: Press the key mapped to QK_BOOT if it is available
